HCBC0408 M4x8mm Socket Head Cap Screw (2 Places) quantity
+
1 M4x8mm Socket Head Cap Screw (2 Places) HCBC0408 REF: 1
HCBC0408
-
ZCKG0001 Gasket, Bleed Screw Fork quantity
+
2 Gasket, Bleed Screw Fork ZCKG0001 REF: 2
ZCKG0001
-
KCCS0004C Fork Cap - Conventional 32mm USD quantity
+
3 Fork Cap - Conventional 32mm USD KCCS0004C REF: 3
KCCS0004C
-
ZCMUOR18 O-Ring – 3mm X 27mm ID quantity
+
4 O-Ring – 3mm X 27mm ID ZCMUOR18 REF: 4
ZCMUOR18
-
KCCS0036 Spring Wear Plate 32mm quantity
+
5 Spring Wear Plate 32mm KCCS0036 REF: 5
KCCS0036
-
KCCS0005 Outer Tube 32mm quantity
+
6 Outer Tube 32mm KCCS0005 REF: 6
KCCS0005
-
KCCS0035 Ring Clip Fork Outer Wear Ring 32mm quantity
+
7 Ring Clip Fork Outer Wear Ring 32mm KCCS0035 REF: 7
KCCS0035
-
KCCS0006 Fork Glide Ring Bottom 32mm quantity
+
8 Fork Glide Ring Bottom 32mm KCCS0006 REF: 8
KCCS0006
-
KCCS0032 Fork Seal Spacer 32mm quantity
+
9 Fork Seal Spacer 32mm KCCS0032 REF: 9
KCCS0032
-
KKCS0004 Fork Seal and Swiper Kit 32mm quantity
+
10 Fork Seal and Swiper Kit 32mm KKCS0004 REF: 10
KKCS0004
-
KCCS0002 Ring Clip - Fork Seal Retainer - 32mm quantity
+
11 Ring Clip - Fork Seal Retainer - 32mm KCCS0002 REF: 11
KCCS0002
-
KCC60067 Fork Jounce Bumper quantity
+
12 Fork Jounce Bumper KCC60067 REF: 12
KCC60067
-
KCCS0013 Fork Spring Guide 32mm quantity
+
13 Fork Spring Guide 32mm KCCS0013 REF: 13
KCCS0013
-
KCCS3225 Standard Spring - Fork 0.25 KG/MM 32mm quantity
+
14 Standard Spring - Fork 0.25 KG/MM 32mm KCCS3225 REF: 14
KCCS3225
-
KCCS3223 Light Spring – Fork 0.23 kg/mm 32mm quantity
+
14 Light Spring – Fork 0.23 kg/mm 32mm KCCS3223 REF: 14
KCCS3223
-
KCCS3227 Heavy Spring - Fork 0.257 KG/MM 32mm quantity
+
14 Heavy Spring - Fork 0.257 KG/MM 32mm KCCS3227 REF: 14
KCCS3227
-
HCNJ3824 Nut Jam 3/8-24 Class 8 quantity
+
15 Nut Jam 3/8-24 Class 8 HCNJ3824 REF: 15
HCNJ3824
-
KCC60068 Ring Clip - Fork Spring Guide Retainer quantity
+
16 Ring Clip - Fork Spring Guide Retainer KCC60068 REF: 16
KCC60068
-
KAC60003 Damper Rod Assembly quantity
+
17 Damper Rod Assembly KAC60003 REF: 17
KAC60003
-
KCC60058 O-Ring Mid-Valve Adj Needle quantity
+
18 O-Ring Mid-Valve Adj Needle KCC60058 REF: 18
KCC60058
-
KCC60050 Fork Mid-Valve Adjuster Needle quantity
+
19 Fork Mid-Valve Adjuster Needle KCC60050 REF: 19
KCC60050
-
KCC60051 Spring - Fork Adjuster Needle quantity
+
20 Spring - Fork Adjuster Needle KCC60051 REF: 20
KCC60051
-
KCCS0018 Seal - Fork Piston - Mid Valve quantity
+
21 Seal - Fork Piston - Mid Valve KCCS0018 REF: 21
KCCS0018
-
HCNJ0601 6mm Jam Nut quantity
+
22 6mm Jam Nut HCNJ0601 REF: 22
HCNJ0601
-
BCKG0033 O-Ring – 2mm ID quantity
+
23 O-Ring – 2mm ID BCKG0033 REF: 23
BCKG0033
-
KCCS0033 Adjuster Screw Top 32mm quantity
+
24 Adjuster Screw Top 32mm KCCS0033 REF: 24
KCCS0033
-
KCC60049 Adjuster Pin quantity
+
25 Adjuster Pin KCC60049 REF: 25
KCC60049
-
KCMU0013 Cartridge Cap quantity
+
26 Cartridge Cap KCMU0013 REF: 26
KCMU0013
-
KCKG0050 Top Out Spring quantity
+
27 Top Out Spring KCKG0050 REF: 27
KCKG0050
-
KCKG0019 Cartridge Tube quantity
+
28 Cartridge Tube KCKG0019 REF: 28
KCKG0019
-
KCMU0021 O-Ring - Fork - Base Valve quantity
+
29 O-Ring - Fork - Base Valve KCMU0021 REF: 29
KCMU0021
-
ZCKGB017 O-Ring - Fork Bottom Plug quantity
+
30 O-Ring - Fork Bottom Plug ZCKGB017 REF: 30
ZCKGB017
-
KCC60069 Fork Bottom Plug – Adjustable quantity
+
31 Fork Bottom Plug – Adjustable KCC60069 REF: 31
KCC60069
-
KCC60048 Adjustment Screw – Fork Bottom Plug quantity
+
32 Adjustment Screw – Fork Bottom Plug KCC60048 REF: 32
KCC60048
-
ZCMUOR03 O-Ring Cylinder Stud (5 Req’d) quantity
+
33 O-Ring Cylinder Stud (5 Req’d) ZCMUOR03 REF: 33
ZCMUOR03
-
KCCS0031 Ring Clip – Fork Adjustment Screw quantity
+
34 Ring Clip – Fork Adjustment Screw KCCS0031 REF: 34
KCCS0031
-
KCCS0007 Fork Glide Ring quantity
+
35 Fork Glide Ring KCCS0007 REF: 35
KCCS0007
-
KAMU0003 Fork Lower – Complete – Brake Side quantity
+
36 Fork Lower – Complete – Brake Side KAMU0003 REF: 36
KAMU0003
-
MCMUTL39 Tool – Fork Seal / Swiper Driver – 32mm quantity
+
Tool Tool – Fork Seal / Swiper Driver – 32mm MCMUTL39 REF: Tool
MCMUTL39
-
MCMUTL32 Tool – Fork Cap Wrench – 32mm quantity
+
Tool Tool – Fork Cap Wrench – 32mm MCMUTL32 REF: Tool
MCMUTL32
-
MCMUTL04 Tool – Cartridge Tube Wrench quantity
+
Tool Tool – Cartridge Tube Wrench MCMUTL04 REF: Tool
MCMUTL04
