HCBC0408 M4x8mm Socket Head Cap Screw (2 Places) quantity
1 M4x8mm Socket Head Cap Screw (2 Places) HCBC0408 REF: 1
HCBC0408
ZCKG0001 Gasket, Bleed Screw Fork quantity
2 Gasket, Bleed Screw Fork ZCKG0001 REF: 2
ZCKG0001
KCCS0004S Fork Cap - Conventional 32mm USD quantity
3 Fork Cap - Conventional 32mm USD KCCS0004S REF: 3
KCCS0004S
ZCMUOR18 O-Ring – 3mm X 27mm ID quantity
4 O-Ring – 3mm X 27mm ID ZCMUOR18 REF: 4
ZCMUOR18
KCCS0036 Spring Wear Plate 32mm quantity
5 Spring Wear Plate 32mm KCCS0036 REF: 5
KCCS0036
KCCS0005 Outer Tube 32mm quantity
6 Outer Tube 32mm KCCS0005 REF: 6
KCCS0005
KCCS0035 Ring Clip Fork Outer Wear Ring 32mm quantity
7 Ring Clip Fork Outer Wear Ring 32mm KCCS0035 REF: 7
KCCS0035
KCCS0006 Fork Glide Ring Bottom 32mm quantity
8 Fork Glide Ring Bottom 32mm KCCS0006 REF: 8
KCCS0006
KCCS0032 Fork Seal Spacer 32mm quantity
9 Fork Seal Spacer 32mm KCCS0032 REF: 9
KCCS0032
KCCS0002 Ring Clip - Fork Seal Retainer - 32mm quantity
11 Ring Clip - Fork Seal Retainer - 32mm KCCS0002 REF: 11
KCCS0002
KCC60067 Fork Jounce Bumper quantity
12 Fork Jounce Bumper KCC60067 REF: 12
KCC60067
KCCS0013 Fork Spring Guide 32mm quantity
13 Fork Spring Guide 32mm KCCS0013 REF: 13
KCCS0013
KCCJ3221 Standard Spring - Fork 0.21 kg/mm 32mm quantity
14 Standard Spring - Fork 0.21 kg/mm 32mm KCCJ3221 REF: 14
KCCJ3221
KCCJ3218 Light Spring - Fork 0.18 kg/mm 32mm quantity
14 Light Spring - Fork 0.18 kg/mm 32mm KCCJ3218 REF: 14
KCCJ3218
KCCJ3225 Heavy Spring - Fork 0.25 kg/mm 32mm quantity
14 Heavy Spring - Fork 0.25 kg/mm 32mm KCCJ3225 REF: 14
KCCJ3225
HCNJ3824 Nut Jam 3/8-24 Class 8 quantity
15 Nut Jam 3/8-24 Class 8 HCNJ3824 REF: 15
HCNJ3824
KCC60068 Ring Clip - Fork Spring Guide Retainer quantity
16 Ring Clip - Fork Spring Guide Retainer KCC60068 REF: 16
KCC60068
KAC60003 Damper Rod Assembly quantity
17 Damper Rod Assembly KAC60003 REF: 17
KAC60003
KCC60058 O-Ring Mid-Valve Adj Needle quantity
18 O-Ring Mid-Valve Adj Needle KCC60058 REF: 18
KCC60058
KCC60050 Fork Mid-Valve Adjuster Needle quantity
19 Fork Mid-Valve Adjuster Needle KCC60050 REF: 19
KCC60050
KCC60051 Spring - Fork Adjuster Needle quantity
20 Spring - Fork Adjuster Needle KCC60051 REF: 20
KCC60051
KCCS0018 Seal - Fork Piston - Mid Valve quantity
21 Seal - Fork Piston - Mid Valve KCCS0018 REF: 21
KCCS0018
HCNJ0601 6mm Jam Nut quantity
22 6mm Jam Nut HCNJ0601 REF: 22
HCNJ0601
BCKG0033 O-Ring – 2mm ID quantity
23 O-Ring – 2mm ID BCKG0033 REF: 23
BCKG0033
KCCS0033 Adjuster Screw Top 32mm quantity
24 Adjuster Screw Top 32mm KCCS0033 REF: 24
KCCS0033
KCC60049 Adjuster Pin quantity
25 Adjuster Pin KCC60049 REF: 25
KCC60049
KCMU0013 Cartridge Cap quantity
26 Cartridge Cap KCMU0013 REF: 26
KCMU0013
KCKG0050 Top Out Spring quantity
27 Top Out Spring KCKG0050 REF: 27
KCKG0050
KCCJ0002 Travel Limiter Spacer quantity
Not shown Travel Limiter Spacer KCCJ0002 REF: Not shown
KCCJ0002
KCKG0019 Cartridge Tube quantity
28 Cartridge Tube KCKG0019 REF: 28
KCKG0019
KCMU0021 O-Ring - Fork - Base Valve quantity
29 O-Ring - Fork - Base Valve KCMU0021 REF: 29
KCMU0021
KCC60057 Plug – Fork Bottom – Smart Leg quantity
30 Plug – Fork Bottom – Smart Leg KCC60057 REF: 30
KCC60057
KCCS0007 Fork Glide Ring quantity
31 Fork Glide Ring KCCS0007 REF: 31
KCCS0007
KAMU0004 Fork Lower – Complete – Non Brake Side quantity
32 Fork Lower – Complete – Non Brake Side KAMU0004 REF: 32
KAMU0004
MCMUTL39 Tool – Fork Seal / Swiper Driver – 32mm quantity
Tool Tool – Fork Seal / Swiper Driver – 32mm MCMUTL39 REF: Tool
MCMUTL39
MCMUTL32 Tool – Fork Cap Wrench – 32mm quantity
Tool Tool – Fork Cap Wrench – 32mm MCMUTL32 REF: Tool
MCMUTL32
MCMUTL04 Tool – Cartridge Tube Wrench quantity
Tool Tool – Cartridge Tube Wrench MCMUTL04 REF: Tool
MCMUTL04
KKCS0004 Fork Seal and Swiper Kit 32mm quantity
Kit Fork Seal and Swiper Kit 32mm KKCS0004 REF: Kit
KKCS0004
