TCCS0009FXX Front Fender – Mega Flo Yellow quantity
1 Front Fender – Mega Flo Yellow TCCS0009FXX REF: 1
TCCS0009FXX
TCMU0034x Front Fender x – Denotes Color Blk, Wht, Yel, Flo quantity
1 Front Fender x – Denotes Color Blk, Wht, Yel, Flo TCMU0034x REF: 1
TCMU0034x
HCBF0620 M6x20 Flange Head Bolt quantity
1A M6x20 Flange Head Bolt HCBF0620 REF: 1A
HCBF0620
TCC60019 Compression Limiting Spacer quantity
1B Compression Limiting Spacer TCC60019 REF: 1B
TCC60019
TCMU0041WHT Number Plate – Front quantity
2 Number Plate – Front TCMU0041WHT REF: 2
TCMU0041WHT
TCMU0041x Front Number Plate x – Denotes Color BLK, WHT, YEL quantity
2 Front Number Plate x – Denotes Color BLK, WHT, YEL TCMU0041x REF: 2
TCMU0041x
HCSP0610 Fork Guard Bolt – Front Number Plate Mount quantity
2A Fork Guard Bolt – Front Number Plate Mount HCSP0610 REF: 2A
HCSP0610
TCCJ0005FXX Radiator Shroud Set (Left & Right) – Mega Flo Yellow quantity
3 & 4 Radiator Shroud Set (Left & Right) – Mega Flo Yellow TCCJ0005FXX REF: 3 & 4
TCCJ0005FXX
TCCJ0005x Radiator Shroud Set x – Color Blk, Wht, Yel, Flo quantity
3 & 4 Radiator Shroud Set x – Color Blk, Wht, Yel, Flo TCCJ0005x REF: 3 & 4
TCCJ0005x
TCCJ0010C Fuel Tank – Clear - No Cap or Petcock – 2017 & Newer quantity
5 Fuel Tank – Clear - No Cap or Petcock – 2017 & Newer TCCJ0010C REF: 5
TCCJ0010C
HCFH0625 M6x25mm Philips Head Screw – Seat & Shroud Hold quantity
5A M6x25mm Philips Head Screw – Seat & Shroud Hold HCFH0625 REF: 5A
HCFH0625
TCHA0005 Spacer – Seat & Shroud Hold quantity
5B Spacer – Seat & Shroud Hold TCHA0005 REF: 5B
TCHA0005
TCHA0006 Spacer – Front Tank Mount (2 Req’d) quantity
5C Spacer – Front Tank Mount (2 Req’d) TCHA0006 REF: 5C
TCHA0006
HCBC0685 M6x85mm SHCS – Front Tank Mount quantity
5D M6x85mm SHCS – Front Tank Mount HCBC0685 REF: 5D
HCBC0685
HCNL0601 M6 Nylock Nut (2 Req’d) quantity
5E M6 Nylock Nut (2 Req’d) HCNL0601 REF: 5E
HCNL0601
HCBF0635 M6x35mm Socket Head Cap Screw quantity
5F M6x35mm Socket Head Cap Screw HCBF0635 REF: 5F
HCBF0635
TCHA0004 Bushing – Rear Tank Mounting quantity
5G Bushing – Rear Tank Mounting TCHA0004 REF: 5G
TCHA0004
TCHA0002 Cap – Fuel Tank quantity
6 Cap – Fuel Tank TCHA0002 REF: 6
TCHA0002
TCHA0003 Hose – Fuel Cap quantity
7 Hose – Fuel Cap TCHA0003 REF: 7
TCHA0003
TCMU0151 Petcock quantity
8 Petcock TCMU0151 REF: 8
TCMU0151
TCCM0007 Seat quantity
9 Seat TCCM0007 REF: 9
TCCM0007
TCCM0007C Cover – Seat Replacement quantity
9A Cover – Seat Replacement TCCM0007C REF: 9A
TCCM0007C
HCBC0604 M6x35mm Socket Head Cap Screw quantity
9B M6x35mm Socket Head Cap Screw HCBC0604 REF: 9B
HCBC0604
MCMU0013 Strap Handle quantity
9C Strap Handle MCMU0013 REF: 9C
MCMU0013
TCCJ0003W Number Plate Set (Left and Right) – White quantity
10 & 11 Number Plate Set (Left and Right) – White TCCJ0003W REF: 10 & 11
TCCJ0003W
TCCJ0003x Number Plate Set x – Denotes Color Blk, Wht, Yel quantity
10 & 11 Number Plate Set x – Denotes Color Blk, Wht, Yel TCCJ0003x REF: 10 & 11
TCCJ0003x
HCBF0616 M6x16mm Flange Head Bolt (2 Req’d) quantity
10A M6x16mm Flange Head Bolt (2 Req’d) HCBF0616 REF: 10A
HCBF0616
HCBF0620 M6x20 Flange Head Bolt quantity
10B M6x20 Flange Head Bolt HCBF0620 REF: 10B
HCBF0620
HCNF0602 M6 Flange Nylock Nut (2 Req’d) quantity
10C M6 Flange Nylock Nut (2 Req’d) HCNF0602 REF: 10C
HCNF0602
HCBF0616 M6x16mm Flange Head Bolt (2 Req’d) quantity
10D M6x16mm Flange Head Bolt (2 Req’d) HCBF0616 REF: 10D
HCBF0616
HCBF0620 M6x20 Flange Head Bolt quantity
10E M6x20 Flange Head Bolt HCBF0620 REF: 10E
HCBF0620
HCNF0602 M6 Flange Nylock Nut (2 Req’d) quantity
10F M6 Flange Nylock Nut (2 Req’d) HCNF0602 REF: 10F
HCNF0602
TCHA0112FXX Fender – Rear – Mega Flo Yellow quantity
12 Fender – Rear – Mega Flo Yellow TCHA0112FXX REF: 12
TCHA0112FXX
TCHA0112x Fender – Rear x – Denotes Color Blk, Wht, Yel, Flo quantity
12 Fender – Rear x – Denotes Color Blk, Wht, Yel, Flo TCHA0112x REF: 12
TCHA0112x
HCBF0616 M6x16mm Flange Head Bolt (2 Req’d) quantity
12A M6x16mm Flange Head Bolt (2 Req’d) HCBF0616 REF: 12A
HCBF0616
FCMU0034 Wedge Spacer – Front Fender quantity
13 Wedge Spacer – Front Fender FCMU0034 REF: 13
FCMU0034
TCCJ2023 Graphic Kit quantity
Accessory Graphic Kit TCCJ2023 REF: Accessory
TCCJ2023
TKCJ2022FXX Bodywork Kit – JR – Stock quantity
Accessory Bodywork Kit – JR – Stock TKCJ2022FXX REF: Accessory
TKCJ2022FXX
TKCJ2022BLK Bodywork Kit - JR - Black quantity
Accessory Bodywork Kit - JR - Black TKCJ2022BLK REF: Accessory
TKCJ2022BLK
TKCJ2022WHT Bodywork Kit - JR - White quantity
Accessory Bodywork Kit - JR - White TKCJ2022WHT REF: Accessory
TKCJ2022WHT
